AVYCON - AVC-NCMS321M04 - 32MP InfiniteColor Multi-Sensor Multi-Directional Diversity IP Camera, 4-Directional Adjustable 4x optical lens, dual light (IR LED & White LED), smart AI, 2ch Alarm In/out, 1 Audio in/out, IK10, IP67, 24VAC/12VDC/PoE+(IEEE8

AVYCON

AVYCON - AVC-NCMS321M04 - 32MP InfiniteColor Multi-Sensor Multi-Directional Diversity IP Camera, 4-Directional Adjustable 4x optical lens, dual light (IR LED & White LED), smart AI, 2ch Alarm In/out, 1 Audio in/out, IK10, IP67, 24VAC/12VDC/PoE+(IEEE8

Name: AVYCON - AVC-NCMS321M04 - 32MP InfiniteColor Multi-Sensor Multi-Directional Diversity IP Camera, 4-Directional Adjustable 4x optical lens, dual light (IR LED & White LED), smart AI, 2ch Alarm In/out, 1 Audio in/out, IK10, IP67, 24VAC/12VDC/PoE+(IEEE8
Brand: AVYCON
SKU: AVC-NCMS321M04
Price: 3777.84 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: AVC-NCMS321M04

$3,777.84

~~$5,440.80~~

Description
Specifications
Downloads
Reviews

32MP Infinite Color Multi-Sensor Multi-Directional Diversity IP Camera, 4-Directional Adjustable 4x optical lens, dual light (IR LED & White LED), smart AI, 2ch Alarm In/out, 1 Audio in/out, IK10, IP67, 24VAC/12VDC/PoE+(IEEE802.3at), includes wall mount.

Features:

4K (8MP) x 4ch multi-directional, each sensor manually adjustable
30fps@8MP (3840x2160) H.265, H.264, MJPEG, Multi-streaming
4 of 2.8-12mm motorized autofocus lens
3D DNR, WDR, HLC, BLC, Smart IR, ROI encoding
Intelligent Analytics
Max. 98ft(30M) IR night view distance
White Light LED Max. 49ft(15M)
24VAC / 12VDC / PoE+ Power
IP67 ingress protection, IK10
Built-in micro SD card slot with video and still image capture function (up to 256GB)
Support three streams
Support remote monitoring by AVYCON ONE (Mobile APP) and AVYCON CMSONE (CMS)

Video
Imaging Device	1/1.8" Progressive CMOS
Resolution	Main Stream : 3840x2160, 3072x1728, 2592x1944, 2592x1520, 2304x1296, 1920x1080, 1280x960, 1280x720 Sub Stream :1280x720, 640 x 480
Max. Framerate	Main Stream: Max. 25fps(60Hz/50Hz) Sub Stream: Max. 25fps (60Hz/50Hz)
Min. Illumination	Color : 0.006lux @ F1.2(AGC on), B/W 0 Lux (IR LED on)
Video Out	N/A
Lens
Focal Length (Zoom Ratio)	4 of 2.8-12mm motorized autofocus lens
Max. Aperture Ratio	F1.3
Angular Field of View	Horizontal: 112°~ 48°, Vertical: 58°~27°, Diagonal: 138°~55°
Min. Object Distance	2.62ft (0.8M) (Wide) ~ 3.28ft (1M) (Tele)
Focus Control	Auto
Lens Type	Φ16.7
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range	Manually adjustable lens-180° to 180°/ 0° to 135° /0° to 355°
Operational
Camera Title	Title displayed up to 32 characters
Day & Night	AUTO (ICR) / Full Color Mode
Backlight Compens	BLC, HLC, WDR
Digital Noise Reduction	3D DNR
Digital Image Stabilization	N/A
Motion Detection	Rectangle Grid (8 Levels of Sensitivity)
Privacy Masking	4 Rectangle Zones
Gain Control	AUTO
White Balance	AUTO / MANUAL
LDC	N/A
Eletronic Shutter Speed	AUTO / Manual (1/5 ~ 1/20000s)
Video Rotation	Flip / Mirror
Analytics	Face Detection（FD） Pedestrian&Vehicle Detection（PD&VD）Intrusion Detection（ID） Line Crossing Detection（TD） Tripwire Counting（TC）Stationary Object Detection（OBJ） Heat Map（HM）Crowd Density Detection（CD）Queue Length Detection（QD） license Plate Detection（LPR）Rare Sound Detection（RSD）
Alarm I/O	2 Inputs / 2 Outputs
Alarm Triggers	Motion, Sound Detection
Alarm Events	Warning Light NotIfication via E-mail Image file upload via FTP Video file upload via FTP Image file upload to Cloud (Drobox) Video file upload to Cloud (Dropbox) Micro SD recording at event triggered Event Push via HTTP / UDP
Audio In	1 Line-In (RCA)
Audio Out	1 Line-Out (RCA)
IR Viewable Length	IR Max. 98ft (30M) / White Light LED Max. 49ft(15M)
Network
Ethemet	RJ45(10/100/1000 BASE-T)
Video Compression	H.265+/H.265 Main Profile, H.264+/H.264 High Profile,MJPEG(Sub Stream Only)
Audio Compression	G.711a / G.711u
Bitrate Control	CBR or VBR (256Kbps ~ 16Mbps)
Streaming	Unicast/Multicast
Protocol	TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
Security	Login Authentication, IP Address Filtering , User access log
Application Programming Interface	ONVIF Profile S/G/T, REST API
General
Webpage Language	English, Korean
Edge Storage	Micro SD/SDHC/SDXC Slot (up to 256GB) with video and still image capture function
Memory	N/A
Environmental & Electrical
Operating Temperature / Humidity	-22 ~ 131 F (-30～+55°C) / less than ≤ 95% RH
Storage Temperature / Humidity	-22 ~ 131 F (-30～+55°C) / less than ≤ 95% RH
Certification	IP67, IK10
Input Voltage	56VDC, 60W PoE+ Injector Included / PoE+(IEEE802.3at) /24VAC / 12VDC
Power Consumption	Max. 43W
Mechanical
Color / Material	Alloy
Product Dimensions / Weight	11.8" x 7.7" (300mm x 195mm) / 4.6kg
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF)
Observe (63PPM/ 19PPF)
Recognize (125PPM/ 38PPF)
Identify (250PPM/ 76PPF)

DataSheet_AVC-NCMS321M04_EN_87afc24c-ce1a-403e-b8cc-fc43a096f026.pdf:

Diversity_20IP_20Quick_20Start_20Guide.pdf:
