Hanwha - TMC-FSCM1PoEM-A - Hardened media fiber converter (A), 100mbps, SC Connector, multi-mode, 1 fiber, PoE+ output, 48V power supply included (not hardened), TMC-FSCM1-B required to work as a pair

The TMC-FSCM1POEM-A Ethernet media converter is a one-channel Ethernet electrical to optical media converters. These auto-negotiating devices accept a 10/100 Mbps electrical input and convert this to a 100 Mbps optical output. Provides full compliance with IEEE 802.3af/802.3at as a Power Sourcing Equipment (PSE), with a maximum power of 30 watts, making them ideal for those applications where the remote equipment draws significant power. LED indicators confirm operational status. Environmentally hardened with no electrical or optical adjustments (Plug and Play). Powered by an included DC power supply (not hardened). May be directly plugged into the SBP-C14 / SBP-C03 Rack or operated as a standalone module. 100Mbps Media Converter, SC Connector, Multi-Mode, 1 fiber, “A” Unit, (requires “A” and “B” units), TMC-FSCM1-B required to work as a pair, 48V, 30W POE output.

Features:

• 10/100 BASE-T/TX electrical port
• 100 BASE-FX optical port
• Power Sourcing Equipment (PSE): Provides IEEE 802.3af/802.3at 30 watts PoE+ for high output demand applications of remote Ethernet equipment
• Electrical port supports Auto-Negotiation for 10 Mbps or
• 100 Mbps, full duplex or half duplex data.
• Optical port supports 100 Mbps full duplex data
• Automatic MDI/MDI-X crossover
• IEEE 802.3 compliant
• Distances up to 3 km (2 mi)
• No in-field optical adjustments required
• LED Indicators
• 48v DC powered using optional power supply
