TP-Link - TL-SG2008P - JETSTREAM 8-PORT GIGABIT SMART PERP SWITCH WITH 8-PORT POE

TP-Link

TP-Link - TL-SG2008P - JETSTREAM 8-PORT GIGABIT SMART PERP SWITCH WITH 8-PORT POE

Name: TP-Link - TL-SG2008P - JETSTREAM 8-PORT GIGABIT SMART PERP SWITCH WITH 8-PORT POE
Brand: TP-Link
SKU: TL-SG2008P
Price: 140.62 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Product SKU: TL-SG2008P

$140.62

Description
Specifications
Downloads
Reviews

JetStream 8-Port Gigabit Smart Switch with 4-Port PoE+

Features:

62 W PoE Budget: 4× 802.3at/af-compliant PoE+ ports with a total power supply of 62 W^*.
Full Gigabit Ports: 4× gigabit PoE+ ports and 4× gigabit non-PoE ports provide high-speed connections.
Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)^**, Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.

Technical Specification
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface	• 8× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3at/af PoE+)
Interface	• Auto-Negotiation/Auto MDI/MDIX
Network Media	• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
Network Media	• 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity	Fanless
Power Supply	• External Power Adapter (Output: 53.5 VDC/ 1.3 A)
Power Consumption	• 7.9 W (no power device connected)
Power Consumption	• 79.2 W (with 62 W power devices connected)
PoE Ports (RJ45)	• Standard: 802.3af/at compliant
	• PoE Ports: 4 Ports
	• Power Supply: 62 W*
Dimensions ( W x D x H )	8.2 x 4.9 x 1.0 in.
Dimensions ( W x D x H )	(209 x 126 x 26mm)
Max Power Consumption	• V1: 69.7 W (220 V/50 Hz) (with 62 W PD connected); 7.9 W (220 V/50 Hz) (no PD connected)
	• V2: 73.8 W (220 V/50 Hz) (with 62 W PD connected)
	• V3: 77.3 W (110 V/60 Hz) (with 62 W PD connected)
Max Heat Dissipation	• V1: 237.82 BTU/hr (220 V/50 Hz) (with 62 W PD connected); 26.95 BTU/hr (220 V/50 Hz) (no PD connected)
	• V2: 251.84 BTU/hr (220 V/50 Hz) (with 62 W PD connected)
	• V3: 263.6 BTU/hr (110 V/60 Hz) (with 62 W PD connected)

PERFORMANCE
Bandwidth/Backplane	16 Gbps
MAC Address Table	8k
Packet Buffer Memory	4.1 Mbit
Jumbo Frame	9 KB

SOFTWARE FEATURES
Quality of Service	• 802.1p CoS/DSCP priority
	• 8 priority queues
	• Priority Schedule Mode
	- SP (Strict Priority)
	- WRR (Weighted Round Robin)
	• Queue Weight Config
	• Bandwidth Control
	- Port/Flow-based Rating Limit
	• Smoother Performance
	• Storm Control
	- Multiple Control Modes(kbps/ratio)
	- Broadcast/Multicast/Unknown-Unicast Control
L2 and L2+ Features	• DHCP Relay
	- DHCP VLAN Relay
	• DHCP L2 Relay
	• Link Aggregation
	- Static link aggregation
	- 802.3ad LACP
	- Up to 8 aggregation groups and up to 8 ports
	per group
	• Spanning Tree Protocol
	- 802.1D STP
	- 802.1w RSTP
	- 802.1s MSTP
	- STP Security: TC Protect, BPDU Filter/Protect,
	Root Protect
	• Loopback Detection
	• Flow Control
	- 802.3x Flow Control
	• Mirroring
	- Port Mirroring
	- CPU Mirroring
	- One-to-One
	- Many-to-One
	- Flow-Based
	- Ingress/Egress/Both
	• Device Link Detect Protocol (DLDP)
	• 802.1ab LLDP/ LLDP-MED
L2 Multicast	• 511 IPv4, IPv6 shared multicast groups
	• IGMP Snooping
	- IGMP v1/v2/v3 Snooping
	- Fast Leave
	- IGMP Snooping Querier
	- Static Group Config
	• Multicast VLAN Registration (MVR)
	• Multicast Filtering
	• MLD Snooping
	- MLD v1/v2 Snooping
	- Fast Leave
	- MLD Snooping Querier
	- Static Group Config
	• Limited IP Multicast (256 profiles and 16 entries per profile)
IPv6 Support	• IPv6 Dual IPv4/IPv6
	• Multicast Listener Discovery (MLD) Snooping
	• IPv6 neighbor discovery (ND)
	• Path maximum transmission unit (MTU) discovery
	• Internet Control Message Protocol (ICMP)
	version 6
	• TCPv6/UDPv6
	• IPv6 applications
	- DHCPv6 Client
	- Ping6
	- Tracert6
	- Telnet (v6)
	- IPv6 SNMP
	- IPv6 SSH
	- IPv6 SSL
	- Http/Https
	- IPv6 TFTP
VLAN	• VLAN Group
	- Max. 4K VLAN Groups
	• 802.1Q tag VLAN
	• MAC VLAN
	• Protocol VLAN
	• GVRP
	• Voice VLAN
Access Control List	• Support up to 230 entries
	• Time-Range
	- Time Slice
	- Week Time-Range
	- Absolute Time-Range
	- Holiday
	• Time-based ACL
	• MAC ACL
	- Source MAC
	- Destination MAC
	- VLAN ID
	- User Priority
	- Ether Type
	• IP ACL
	- Source IP
	- Destination IP
	- IP Protocol
	- TCP Flag
	- TCP/UDP Source Port
	- TCP/UDP Destination Port
	- DSCP/IP TOS
	• IPv6 ACL
	• Combined ACL
	• Rule Operation
	- Permit/Deny
	• Policy Action
	- Mirror
	- Rate Limit
	- Redirect
	- QoS Remark
	• ACL Rules Binding
	- Port Binding
	- VLAN Binding
	• Actions for flows
	- Mirror (to supported interface)
	- Redirect (to supported interface)
	- Rate Limit
	- QoS Remark
Security	• AAA
	• 802.1X
	- Port-based authentication
	- MAC (Host) based authentication
	- Authentication Method includes PAP/EAP-MD5
	- MAB
	- Guest VLAN
	- Support Radius authentication and
	accountability
	• IP/IPv6-MAC Binding
	- 512 Binding Entries
	- DHCP Snooping
	- DHCPv6 Snooping
	- ARP Inspection
	- ND Detection
	• IP Source Guard
	- 253 Entries
	- Source IP+Source MAC
	• IPv6 Source Guard
	- 183 Entries
	- Source IPv6 Address+Source MAC
	• DoS Defend
	• Static/Dynamic/Permanent Port Security
	- Up to 64 MAC addresses per port
	• Broadcast/Multicast/Unicast Storm Control
	- kbps/ratio control mode
	• Port Isolation
	• Secure web management through HTTPS with
	SSLv3/TLS 1.2
	• Secure Command Line Interface (CLI)
	management with SSHv1/SSHv2
	• IP/Port/MAC-based access control
Advanced Features	• Automatic Device Discovery
	• Batch Configuration
	• Batch Firmware Upgrading
	• Intelligent Network Monitoring
	• Abnormal Event Warnings
	• Unified Configuration
	• Reboot Schedule
MIBs	• MIB II (RFC1213)
	• Bridge MIB (RFC1493)
	• P/Q-Bridge MIB (RFC2674)
	• Radius Accounting Client MIB (RFC2620)
	• Radius Authentication Client MIB (RFC2618)
	• Remote Ping, Traceroute MIB (RFC2925)
	• Support TP-Link private MIBs
	• RMON MIB(RFC1757, rmon 1,2,3,9)

MANAGEMENT
Omada App	Yes, through
	• Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2)
	• OC300
	• OC200
	• Omada Software Controller
Centralized Management	• Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2)
	• Omada Hardware Controller OC300
	• Omada Hardware Controller OC200
	• Omada Software Controller
Cloud Access	Yes, through
	• Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2)
	• OC300
	• OC200
	• Omada Software Controller
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller (Supported by TL-SG2428P v1, v3 and above, while is not supported by TL-SG2428P v2)
Management Features	• Web-based GUI
	• Command Line Interface (CLI) through telnet
	• SNMPv1/v2c/v3
	• SNMP Trap/Inform
	• RMON (1,2,3,9 groups)
	• SDM Template
	• DHCP/BOOTP Client
	• Dual Image, Dual Configuration
	• CPU Monitoring
	• Cable Diagnostics
	• EEE
	• SNTP
	• System Log

OTHERS
Certification	CE, FCC, RoHS
Package Contents	• TL-SG2008P
	• Power Adapter
	• Installation Guide
	• Rubber Feet
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉);
	• Storage Temperature: -40–70 ℃ (-40–158 ℉)
	• Operating Humidity: 10–90% RH non-condensing
	• Storage Humidity: 5–90% RH non-condensing
