GeoVision - GV-TVD4700 - 4MP H.265 Super Low Lux WDR IR Vandal Proof IP Dome

Name: GeoVision - GV-TVD4700 - 4MP H.265 Super Low Lux WDR IR Vandal Proof IP Dome
Brand: GeoVision
SKU: GV-TVD4700
Price: 179.82 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: GV-TVD4700

$179.82

~~$450.00~~

Description
Specifications
Downloads
Reviews

The Vandal Proof IP Dome is an outdoor camera designed with IK10 vandal resistance and IP67 ingress protection. GV-TVD4700 supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. The camera is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adjustable in 3 axes (pan, tilt and rotate), it offers an entry-level surveillance solution with all the essential features and excellent image quality.

Features:

1/3" progressive scan super low lux CMOS
Min. illumination at 0.01 lux
Triple streams from H.265, H.264 or MJPEG
Up to 20 fps at 2592 x 1520
Intelligent IR
IR distance up to 30 m (100 ft)
Day and Night function (with removable IR-cut filter)
Vandal resistance (IK10 for metal casing)
Ingress protection (IP67)
3-axis mechanism (pan / tilt / rotate)
DC 12V / PoE (IEEE 802.3af)
Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10) for local storage
Wide Dynamic Range (WDR)
Defog
3D noise reduction
Motion detection
Text overlay
Privacy mask
Tampering alarm
ONVIF (Profile G, S, T) conformant

Camera
Image Sensor	1/3” progressive scan super low lux CMOS
Picture Elements	2592(H) x 1520 (V)
Minimum Illumination	Color 0.01 Lux (F1.6, AGC ON) IR On 0 Lux
Shutter Speed	Automatic, Manual (1/25 ~ 1/100000 sec)
White Balance	Automatic, Manual
Gain Control	Automatic, Manual
S/N Ratio	52 dB
WDR	Yes
Dynamic Range	Up to 72 dB
Lens
Megapixel	4 MP
Day/Night	Yes (with removable IR-cut filter)
Focal Length	2.8 ~ 12 mm
Lens Type	Varifocal lens
Maximum Aperture	F/1.6
Mount	Ø 14 mm
Horizontal FOV	97°~ 29°
Operation	Focus Manual (w/ lock) Zoom Manual (w/ lock) Iris Fixed
IR LED Quantity	2 IR LEDs
Max. IR Distance	30 m (100 ft)
Operation
Video Compression	H.265, H.264, MJPEG
Video Streaming	Triple streams
Frame Rate	20 fps at 2592 x 1520 (60 / 50 Hz) * The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).
Video Analytics	Motion Detection, Tampering Alarm, Intrusion, Human Body Detection
Image Setting	Brightness, Contrast, Saturation, Sharpness, Flicker-less, 3D Noise Reduction, Image Orientation (Flip, Mirror, 0°, 180°), Exposure Mode, Shutter Speed, Gain Control, Slow Shutter, Backlight Compensation (BLC), Metering Control, D/N Sensitivity, WDR, Smart Illumination, White Balance, Defog
Video Resolution
Video Resolution	Main Stream 2592 x 1520 (Default), 2048 x 1520, 1920 x 1080 Sub Stream 1920 x 1080, 1280 x 720, 720 x 576, 704 x 288, 640 x 360 (Default), 352 x 288 Third Stream (Closed by Default) 720 x 576, 704 x 288, 640 x 360, 352 x 288
Network
Interface	10/100 Ethernet
Ethernet Protocol	ARP, DHCP, DDNS, DNS, DynDNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, NTP, PPPoE, QoS,RTCP, RTP, RTSP, SMTP, TCP, UDP, UPnP, ONVIF (Profile G, S, T)
Mechanical
Camera Angle Adjustment	Pan 0 ~ 360° Tilt 0 ~ 80° Rotate 0 ~ 360°
Connectors	Power DC Jack (DC 12V, 1A), PoE (IEEE802.3af) Ethernet RJ-45 Local Storage Micro SD card slot (SD / SDHC / SDXC / UHS-I, Class 10) * UHS-II card type is not supported.
General
Environment Temperature	‐40 ~ 60°C (‐40 ~ 140°F)
Humidity	0 ~ 95% (no condensation)
Power Source	12 V DC / PoE (IEEE 802.3af)
Max. Power Consumption	7 W
Dimension	Ø 148 x 111.3 mm (Ø5.8 x 4.4”)
Weight	0.92 kg (2 lb)
Ingress Protection	IP67
Vandal Resistance	IK10 for metal casing
Regulatory	CE, FCC, RoHS compliant
Web Interface
Installation Management	Web-based configuration
Maintenance	Firmware upgrade through Web Browser or Utility
Access from Web Browser	Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Text Overlay, Image Masking
Language	Czech, English, French, German, Italian, Russian, Traditional Chinese
Applications
Network Storage	GV-VMS (V17.3.0 / V18.1.1), GV-DVR / NVR (V8.8), GV-Control Center (V3.7.0),GV-Recording Server / Video Gateway (V1.4.2), GV-Edge Recording Manager Win version (V1.4.0), GV-Redundant / Failover Server (V1.1.0.0) *It is required to apply patch files to all the supported software
Smart Device Access	GV-Eye for iOS and Android
Live Viewing	Browser (IE, Edge, Chrome, Safari, Firefox), Mobile App
