Digital Watchdog - DWC-MD72i4V - 2.1MP/1080p indoor dome IP camera with 4.0mm fixed lens and IR


Image Sensor

1/2.7“ 2.1M CMOS

Total Pixels

1930 x 1088

Minimum Scene Illumination

F2.0 (30IRE): 1.4 Lux [Color]
F2.0 (30IRE): 0.00 Lux [B/W]

LENS

Focal Length

4.0mm Lens, F2.0

Lens Type

Fixed Lens

IR Distance

30ft Smart IR™

Angle of View

82°

OPERATIONAL

Shutter Mode

Auto

Shutter Speed

1/30(25)sec ~ 1/10,000sec

White Balance

Auto Indoor/Auto Outdoor/Push/Manual/Hold

Auto Gain Control

Max 64dB

Day and Night

Auto, Day, Night, Schedule

NETWORK

LAN

802.3 Compliance 10/100 base T LAN

Video Compression Type

H.264, MJPEG

Resolution

1080p / D1 / VGA / CIF / QVGA

Frame Rate

1-30fps

Streaming Capability

Multi Streaming CBR/VBR (Controllable frame rate and Bandwidth)

IP

IPv4, IPv6

Protocol

ONVIF, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, DNS, DDNS, DHCP

Maximum User Access

4 Users

ONVIF Conformance

ONVIF Profile S

Web Viewer

Browser: Internet Explorer, Google Chrome, Firefox OS: Windows 7

ENVIRONMENTAL

Operating Temperature

-10°C ~ 50°C (14°F ~ 122°F)

Operating Humidity

Less than 90% (Non-Condensing)

Other Certifications

FCC, CE, ROHS

ELECTRICAL

Power Requirements

DC 12V, POE IEEE 802.3af Class 2

Power Consumption

LED Off: 2.0W, 165mA
LED On: 2.9W, 240mA

MECHANICAL

Material

Plastic

Dimensions

4.13 x 2.93 in (105 x 74.6mm)

Weight

0.55lbs (250g)
