Planet - ICF-1900 - High Definition Touch Color Screen Smart Media Android SIP Conference Phone
Planet - ICF-1900 - High Definition Touch Color Screen Smart Media Android SIP Conference Phone
Planet - ICF-1900 - High Definition Touch Color Screen Smart Media Android SIP Conference Phone
Planet - ICF-1900 - High Definition Touch Color Screen Smart Media Android SIP Conference Phone
Planet - ICF-1900 - High Definition Touch Color Screen Smart Media Android SIP Conference Phone
Planet - ICF-1900 - High Definition Touch Color Screen Smart Media Android SIP Conference Phone
Planet

Planet - ICF-1900 - High Definition Touch Color Screen Smart Media Android SIP Conference Phone

Product SKU: ICF-1900
Available:
Only 1000 items in stock
1000 items in stock
In stock
Pre-order
Out of stock
$456.84
Notify me When Available
You will receive an email when the product is available.
  • Description
  • Specifications
  • Downloads

High Definition Touch Color Screen Smart Media Android SIP Conference Phone:  Android 9.0, IETF SIP 2.0, HD/Opus Audio, H.264 Video, 7" LCD, 20 SIP Lines, Dual Gigabit LAN, 802.3at/af POE, 2.4G/5G Wi-Fi, Bluetooth, BLF, QoS, STUN, VPN, DND, TLS, Caller ID, 5-Way Conference, Auto Provision, TR-069, PLANET DDNS



Features:

  • Video Conference Phone with 7-inch Touch Screen
  • High-quality G.722 HD and Opus Audio Codes
  • Secure, High-quality VoIP Communication
  • Standard Compliance and Enhanced Voice Security
  • Enterprise Conference Telephony Deployment of ICF-1900



Highlights

  • 7-inch color touch screen with Android 9.0 OS
  • Plug and Play optional 1080p USB camera with 720p 30fps H.264 video call
  • IETE SIP compliant with Transport Layer Security
  • Up to 20 SIP lines with 112 one-touch DSS keys
  • Dual Gigabit and IEEE 802.3af/at PoE compliant
  • Built-in Bluetooth 4.2 and 2.4G/5G Wi-Fi
  • Wideband G.722 HD and Opus audio codec with handset and hands-free function



Audio and Video Features

  • 720p 30fps HD H.264 video call
  • Audio codec: Opus, G.722, G.722.1, G.722.1C,G.711 (A/µ), G.729AB, iLBC
  • DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
  • Full-duplex hands-free speakerphone with AEC
  • Noise Reduction (NR) and Packet Loss Concealment (PLC)



Phone and Call Control Features

  • Up to 3-party video conferencing and 5-party video/audio mixed conferencing
  • Direct IP call without SIP proxy or IP PBX
  • Caller ID display, speed dial, do not disturb (DND)
  • One-touch speed dial, hotline, black/white list call filter
  • Local phonebook (2000 entries),  remote phonebook (XML/LDAP, 2000 entries)
  • Call logs (In/out/missed, 1000 entries)



Network and Management

  • Integrated web server provides web-based administration and configuration
  • Telephone keypad configuration via display menu/navigation
  • OpenVPN, VLAN and QoS Support
  • Auto-provisioning via FTP, TFTP, HTTP/HTTPS, DHCP OPT66, SIP PNP, TR-069
Interface
Lines (Direct Numbers)20 SIP Lines
Display and Indicator112 one-touch DSS keys on 7-inch (1024 x 600) color touch screen
5 points multi-touch surface
Screensaver and wallpaper
LED for call and message waiting indication
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name, number and photo
Feature Keys26 keys, including
5 x Function keys (Hold, MWI, Mute, Headset, Redial)
4 x Navigation keys
1 x OK key
1 x Return key 
12 x Standard Phone Digits keys
2 x Volume Control keys – Up and Down
1 x Hands-free key
Network InterfacesDual-port Gigabit Ethernet:
Network x 1 (802.3af/at PoE enabled)
PC x 1 (Bridged Network)
Built-in Wi-Fi (2.4GHz/5Gz)
Built-in Bluetooth 4.2
ConnectorsRJ9 Port x 2: Handset x 1, Headset x 1
USB2.0 Port x 1: Standard A, Connect with camera
Safety keyhole x 1
Android bundled Applications
Operating SystemAndroid 9.0 OS with higher security and better compatibility
Files, Calendar, Gallery, Browser, Email, Calculator, Notepad,
Sound Recorder, Clock, Video, Music
Third-party Android application support
Network and Provisioning
NetworkIP Mode:IPv4
IP Configuration: Static / DHCP
Network Access Control: 802.1x
VPN: OpenVPN (Requires third-party app support)
VLAN, LLDP, CDP, QoS
ProtocolsSIP2.0 over UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, CDP, LLDP, PPPoE, 802.1x, OpenVPN (Requires third-party app support), SNTP, FTP/TFTP, HTTP/HTTPS, TR-069
Deployment & MaintenanceAuto-provisioning via FTP, TFTP, HTTP/HTTPS, DHCP OPT66, SIP
PNP, TR-069
Web management portal, Telnet
Encrypted configuration files download with AES
Web upgrade, factory reset data
The third-party communication App
Features
Audio FeaturesHD voice microphone/speaker (handset/hands-free, 0 ~ 7KHz
frequency response)
HAC handset
Wideband ADC/DAC 16KHz sampling
Narrowband codec: G.711a/u, G.729AB, iLBC
Wideband codec: G.722, Opus
Full-duplex acoustic echo canceller (AEC)
Noise reduction (NR)
Packet loss concealment (PLC)
Dynamic adaptive jitter buffer
DTMF: In-band, out-of-band, DTMF-relay (RFC2833), SIP Info
Video FeaturesVideo decoding: H.264
Video call resolution: CIF/VGA/4CIF/720P/1080P
Image format: JPEG/PNG/BMP
Video format: MP4
Bandwidth selection: 64kbps~4Mbps
Frame rate selection: 5~30fps
Video from remote site can be displayed in full screen
3-way video conferencing
Self-view (local video preview)
Phone FeaturesLocal Phonebook (2000 entries)
Remote Phonebook (XML/LDAP, 2000 entries)
Intelligent Search for Contacts and Call Log
Call logs (In/out/missed, 1000 entries)
Black/White List Call Filter
Screen saver
Voice Message Waiting Indication (VMWI)
Programmable DSS/Soft keys
Network Time Synchronization
Built-in Bluetooth 4.2: Supports Bluetooth headset/ Bluetooth of Mobile Device
Built-in Wi-Fi: 2.4GHz, 802.11 b/g/n, 5GHz, 802.11 a/n/ac
Support Recording
Action URL / Active URI
UaCSTA
Audio/Video Recording
SIP Hotspot
Group Broadcasting
Action Plan
Group listening
Call FeaturesCall out / Answer / Reject
Mute / Unmute (Microphone)
Call Hold / Resume
Call Waiting
Intercom
Caller ID Display
Speed Dial
Anonymous Call (Hide Caller ID)
Call Forwarding (Always/Busy/No Answer)
Call Transfer (Attended/Unattended)
Call Parking/Pick-up (Depending on server)
Redial
Do-Not-Disturb
Auto-Answering
Voice Message (On IP PBX or SIP server)
5-way Audio Conferencing
Hot Line
Hot desking
BLF (Busy Lamp Field)
Environment
Power RequirementsIEEE 802.3af/at (Network port)
5V DC, 2000mA (optional external power supply)
Power ConsumptionPoE: 1.596~11.86W
Adapter: 0.907~9.38W
Operating Temperature0 ~ 45 degrees C
Operating Humidity10 ~ 95% (non-condensing)
Weight770g
Dimensions (W x D x H)Desktop Stand (Angle 1): 268 x 185 x 189 mm
Desktop Stand (Angles 2): 268 x 201 x 168 mm
EmissionCE, FCC, RoHS


Optional Accessories -- ICF-CAM80
CameraPixels: 2 megapixels
Video Codec: H.264
Video Call Resolution: 1080p@30fps
Automatic/Manual White Balance
Automatic Exposure Compensation
Adjustable with Privacy Shutter
View Diagonal: 102°
Horizontal: 94°
Vertical: 62°
Vertical Adjustment Angle: ± 23 °
Status Indicator Light x1 (with Two-color LED)
Environments
Power Requirements / Consumption5V @ <500mA via USB port
Operating Temperature-10 ~ 50 degrees C
Operating Humidity10 ~ 90% (non-condensing)
Weight119 g
Dimensions (W x D x H)51 x 90.14 x 141.31 mm
EmissionCE, FCC, RoHS
ConnectorsUSB Port x1: Micro USB 2.0
ICF-1900_EC_Declaration_0_9af0a7b8-bb36-462a-b6e1-05a1729a7e8b.pdf:
ICF-1900_Quick_Installation_Guide_0_dcbe407b-d6a1-4516-aa81-bf51b9ed7f5c.pdf:
