BOLIDE - SVR9504H/NDAA - 4-Channel H.265 5MP HD Over Coax / IP Hybrid DVR, Supports AHD / TVI / CVI/ Analog Formats, 10Mbps IP Throughput, 4K Output, HDMI and VGA, 4-Channel Audio In/ 1-Channel Audio Out, 1 SATA Hard Drive Bay Up to 12TB, QuickConnec

Name: BOLIDE - SVR9504H/NDAA - 4-Channel H.265 5MP HD Over Coax / IP Hybrid DVR, Supports AHD / TVI / CVI/ Analog Formats, 10Mbps IP Throughput, 4K Output, HDMI and VGA, 4-Channel Audio In/ 1-Channel Audio Out, 1 SATA Hard Drive Bay Up to 12TB, QuickConnec
Brand: Bolide
SKU: SVR9504H/NDAA
Price: 228.42 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: SVR9504H/NDAA

$228.42

~~$350.22~~

Description
Specifications
Downloads
Reviews

4-Channel H.265 5MP HD Over Coax / IP Hybrid DVR, Supports AHD / TVI / CVI/ Analog Formats, 10Mbps IP Throughput, 4K Output, HDMI and VGA, 4-Channel Audio In/ 1-Channel Audio Out, 1 SATA Hard Drive Bay Up to 12TB, QuickConnect, NDAA Compliant

Features:

4K / 5MP Resolution
NDAA Compliant
Hybrid DVR - Additional IP Channels
1 HDD Bay Up to 12TB
1 HDMI, 1 VGA Outputs
Built-in Video Analytics
Bolide QuickConnect Enabled
iPac AI Enabled

Display
Resolution	VGA: 1024x768,1280x720, 1280x1024, 1440x900, 1920x1080
Resolution	HDMI: 1024x768,1280x720, 1280x1024, 1440x900, 1920x1080, 2560x1440, 3840x2160
Feature	Single/Quad/S.E.Q/
Record
Resolution	Analog
	5MP/4MP/3MP/1080P/720P/960H
	IP
	5MP/4MP/3MP/1080P/720P/960H
Speed	Analog: 8MP: 7FPS / Channel, 5MP:12FPS / Channel, 4MP:15FPS / Channel, 1080P: PAL: 25FPS / Channel,
	NTSC: 30FPS / Channel
	IP: PAL: 25FPS / Channel, NTSC: 30FPS / Channel
	Sub-Stream
	PAL：704x576: 10FPS/Channel, NTSC：704x480:10FPS/Channel
Video Compression	H.265 / H.264
Video System	NTSC/PAL
Operating System	Linux (embedded)
Analog video input/output	4-Channel BNC / VGA & HDMI Output
IP Video Input	2-Channels
Composite Video Input	Up to 6 Channels ( Analog & IP )
Audio Input/Output	4 Audio In / 1 Audio Out
IP-Recording Bandwidth	12Mbps
Max. Output Bandwidth	48Mbps
Recording Mode	Continuous / Manual / Motion Detection / Alarm / Video Analytics
Synchronous Playback	4 Channels
Network Type	LAN, DHCP
HDD Interface	1 SATA HDD, up to 12TB
USB	1 USB 2.0 ( Front ), 1 USB 2.0 ( Rear )
PTZ Control	Control Over Coax, RS-485
Mobile Surveillance	Bolide Quick Connect on iOS / Android
Power Supply	DC12V / 2A
Dimension	11.8" x 8.2" x 1.89"
Working Temperature	32°F~+104°F
Working Humidity	10%~90%
