- Digital Watchdog - DW-BJPR2U64T - 64TB Blackjack P-Rack 2U 8-Bay Chassis with RAID Digital Watchdog - DW-BJPR2U64T - 64TB Blackjack P-Rack 2U 8-Bay Chassis with RAID
36% $8,000.28
Digital Watchdog
Digital Watchdog - DW-BJPR2U64T - 64TB Blackjack P-Rack 2U 8-Bay Chassis with RAID
Product SKU: DW-BJPR2U64T
Available:
Only 1000 items in stock
1000 items in stock
In stock
Pre-order
Out of stock
$14,265.72
- Description
- Specifications
- Downloads
- Reviews
Blackjack P-Rack servers are NDAA and TAA compliant and can record and manage single- and multi-sensor IP cameras of any resolution with a maximum of 600Mbps throughput. Standard features include Intel i7, Windows 10 IoT or Linux Ubuntu 18.04 LTS OS on separate SSD and 2x NIC cards. Blackjack P-Rack servers come preloaded with the DW Spectrum IPVMS suite, can be configured with 64-96TB RAID5 recording storage and come with our 5 year limited warranty.
Features :
- Supports All ONVIF conformant IP cameras
- Storage options 64-96TB internal storage, 48-80TB usable storage
- Data redundancy
- Record and manage single- and multi-sensor IP cameras of any resolution up to 600Mbps throughput
- True HD and DVI local monitoring outputs ports
- Dual network ports
- Windows 10 IoT or Linux Ubuntu 18.04 LTS OS on separate SSD
- Hosting DW Spectrum IPVMS for setup, configuration, monitoring and recording
- One-time recording license charge, fully transferable between cameras and encoders
- One (1) DW Spectrum IPVMS 4-channel licenses included (DW-SPECTRUMLSC004)
- No annual maintenance fees
- Simple enterprise scalability
- Auto device discovery
- Dual stream recording
- Rail kit included
- USB mouse and keyboard included
- Designed, assembled and tested in the U.S.A.
- NDAA/TAA compliant
- 5 years limited warranty
| Video | |
|---|---|
| Compression | H.264 H.265 |
| CPU | Intel i7® processor |
| Display Modes | Unlimited Sequence Customizable |
| Display Speed | Up to 30fps per channel |
| Local Video Outputs | True HD VGA DVI 1 display output at a time |
| Memory | 16GB |
| Operating System | Linux OS Windows®10 |
| Video Card | GeForce 210 512MB Option: DW-RV4H - 4 head HD video card* * Available at initial order only |
| OS on SSD | 150GB SSD (RAID1 mirrored) Option: DW-SSD80 – second SSD for mirroring the OS * * Available at initial order only |
| Storage | |
| Max HDD Bay | 6 x SATA HDD |
| Maximum Storage | 70TB RAID 5 (60TB usable storage) |
| General | |
| Accessories | Keyboard Mouse |
| Certification | NDAA Compliance ONVIF Conformant TAA Compliance |
| Form Factor | Rack mount |
| General Dimensions | 17.29” x 21.93” x 3.5” (439.3 x 557.1 x 88.9 mm) |
| General Warranty | 5 Year Limited Warranty |
| Included IP licenses | 4 |
| Max video storage rate (Mbps) | 600Mbps |
| Operating Temperature and Humidity | 41 ~ 104 °F (5~40 °C) 20 ~ 90% RH |
| Power Consumption | 400W A UPS is recommended |
| Rail kit | Included |
| Serial ports | ONVIF |
| System Operation | Graphical user interface (GUI) USB mouse (included) Remote via DW Spectrum IPVMS |
| USB interface | Yes |
| Network | |
| Backup | Network backup via DW Spectrum IPVMS |
| Ethernet Ports | 2x 1G Ethernet (RJ45) |
| Ethernet Ports (Product Specification) | Option: DW-R2NIC - upgrade dual 1GB NIC card OR DW-R4NIC - upgrade quad 1GB NIC card * * Available at initial order only |
| Pre-loaded VMS software | DW Spectrum® IPVMS |
| Remote Software | DW Site Viewer for Apple TV DW Spectrum Mobile App Cross-platform - Windows®, Linux Ubuntu® and Mac® DW Mobile Plus |
| Performance | |
| Playback Functions | Timeline Calendar Event search Thumbnail search Smart motion search |
| PTZ control | ONVIF |
| Recording Modes | Continuous Motion detection Motion + low res always Object only Object + Low res Motion + Object Motion + Object + Low res |
Part Numbers
Model #* |
Usable Storage Size** |
| DW-BJPR2U64T | 48TB |
| DW-BJPR2U96T | 80TB |
