Hanwha - XNO-8020R - Wisenet X powered by Wisenet 5 network outdoor vandal bullet camera, 5MP @30fps, 3.7mm fixed lens (97.5°), triple codec H.265/H.264/MJPEG with WiseStream II technology, 120dB WDR, USB port for easy installation, advanced video an

Hanwha Vision

Hanwha - XNO-8020R - Wisenet X powered by Wisenet 5 network outdoor vandal bullet camera, 5MP @30fps, 3.7mm fixed lens (97.5°), triple codec H.265/H.264/MJPEG with WiseStream II technology, 120dB WDR, USB port for easy installation, advanced video an

Name: Hanwha - XNO-8020R - Wisenet X powered by Wisenet 5 network outdoor vandal bullet camera, 5MP @30fps, 3.7mm fixed lens (97.5°), triple codec H.265/H.264/MJPEG with WiseStream II technology, 120dB WDR, USB port for easy installation, advanced video an
Brand: Hanwha Vision
SKU: XNO-8020R
Price: 816.48 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: XNO-8020R

$816.48

~~$1,080.00~~

Description
Specifications
Downloads
Reviews

Wisenet X powered by Wisenet 5 network outdoor vandal bullet camera, 5MP @30fps, 3.7mm fixed lens (97.5°), triple codec H.265/H.264/MJPEG with WiseStream II technology, 120dB WDR, USB port for easy installation, advanced video analytics and sound classification and business analytics, high powered IR LEDs range of 98', true D/N, dual SD card, hallway view, HLC, defog detection, DIS, backbox included, 12VDC/PoE, IP67, IK10, Nema 4X

Features:

Built-in 3.7mm fixed lens
Max. 30fps@all resolutions (H.265/H.264)
Loitering, Directional detection, Fog detection, Audio detection, Digital auto tracking, Sound classification, Heatmap, People counting, Queue management, Tampering
Motion detection, Handover
Dual SD slots (Max. 512GB),WiseStream II support
IR viewable length 30m, IP67/IP66, NEMA 4X, IK10

Video
Imaging Device	1/1.8" 6M CMOS
Effective Pixels	2,616(H) x 1,976(V)
Minimum Illumination	Color : 0.2Lux (F1.6, 1/30sec), B/W : 0Lux (IR LED on)
Video Out	CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation USB : micro USB type B, 1280 x 720 for installation

Lens
Focal Length (Zoom Ratio)	) 3.7mm fixed (XNO-8020R)
Maximum Aperture Ratio	F1.6
Angular Field of View	H : 97.5˚ / V : 71.9˚/ D : 126.2˚ (XNO-8020R)
Minimum Object Distance	0.4m (1.31ft)
Focus Control	Manual
Lens Type	Fixed / Board-in type

Operational
IRViewable Length	30m (98.43ft)
Camera Title	Off / On (Displayed up to 85 characters) - W/W : English / Numeric / Special characters - China : English / Numeric / Special / Chinese characters - Common : Multi-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White), Transparency, Auto scale by resolution
Day & Night	Auto (ICR)/ Color/ B/W / External / Schedule
Backlight Compensation	Off / BLC / HLC (Masking / Dimming), WDR
Wide Dynamic Range	120dB
Digital Noise Reduction	SSNRV (2D+3D noise filter) (Off / On)
Digital Image Stabilization	Off / On
Defog	Off / Auto (Input from fog detection)/ Manual
Motion Detection	Off / On (8ea, 8point polygonal zones), Handover
Privacy Masking	Off / On (32ea, Polygonal) - Color : Grey / Green / Red / Blue / Black / White, Mosaic
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual/Indoor / Outdoor (Included mercury & Sodium)
LDC	Off / On (5 levels with min / max)
Electronic Shutter Speed	Minimum / Maximum / Anti icker (2 ~ 1/12,000sec)
Digital PTZ	24x, Digital PTZ (Preset, Group)
Flip / Mirror	Off / On, Hallway view : 90˚/270˚
Alarm I/O	Input 1ea / Output 1ea
Alarm Triggers	Alarm input, Motion detection, Video & Audio analytics, Network disconnect
Alarm events	File upload via FTP, E-mail, Notification via E-mail, Localstorage (SD/SDHC/ SDXC) or NAS recording at event triggers, External output, DPTZ preset
Audio In	Selectable(Mic in/Line in), Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out	Line out, Maximum output level: 1Vrms

Hanwha_20Techwin_20America_20-_20NDAA_20Compliant_20Product_20List_175.pdf:

xno-8020r-_specifications_0_f029b9b6-5c31-411f-8c65-2d9ee16cabef.pdf:
