Uniview - KIT/NVR301-08LS2-W/8*IPC2122LR3-F40W-E - UNV 1 Hard Disk 8-Channel WIFI NVR Kit (Including 8 PCS 2MP WiFi Network IR Fixed Bullet)

Uniview - KIT/NVR301-08LS2-W/8*IPC2122LR3-F40W-E - Uniview 1 Hard Disk 8-Channel WIFI NVR Kit (Including 8 PCS 2MP WiFi Network IR Fixed Bullet)

Name: Uniview - KIT/NVR301-08LS2-W/8*IPC2122LR3-F40W-E - Uniview 1 Hard Disk 8-Channel WIFI NVR Kit (Including 8 PCS 2MP WiFi Network IR Fixed Bullet)
Brand: Uniview
SKU: KIT/NVR301-08LS2-W/8*IPC2122LR3-F40W-E
Price: 565.38 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: KIT/NVR301-08LS2-W/8*IPC2122LR3-F40W-E

$565.38

~~$1,402.80~~

Description
Specifications
Downloads
Reviews

UNV 1 Hard Disk 8-Channel WIFI NVR Kit (Including 8 PCS 2MP WiFi Network IR Fixed Bullet)

Features:

NVR301-08LS2-W

Embedded WiFi Module with high-performance and high stability
Support CCMP encryption and WPA2-PSK authentication, Support IP cameras with WiFi in access
Support Ultra 265/H.265/H.264 video formats
8-channel input
Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
Support 1-ch HDMI, 1-ch VGA
HDMI and VGA synchronous outputs provided
Up to 5MP resolution recording
1 SATA HDD, Up to 6TB for each HDD
Support cloud upgrade

IPC2122LR3-F40W-E

Day/night functionality
Smart IR , up to 30 m (98 ft) IR distance
Optical glass window with higher light transmittance
IR anti-reflection window to increase the infrared transmittance
2D/3D DNR (Digital Noise Reduction)
Ultra 265,H.265, H.264
Dual streams
ONVIF Conformance
Wide temperature range:-30°C ~ +60°C (-22°F ~ 140°F)
Wide voltage range of ±25%  IP67

Model	NVR301-08LS2-W
Video/Audio Input
IP Video Input	8-ch
Network
Incoming Bandwidth	40Mbps
Outgoing Bandwidth	40Mbps
Remote Users	128
Protocols	P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
HDMI/VGA Output	HDMI: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
Recording Resolution	5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output	1-ch, RCA
Synchronous Playback	8-ch
Corridor Mode Screen	3/4
Decoding
Decoding format	Ultra 265/H.265/H.264
Live view/ Playback	5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability	1 x 5MP@30, 2 x 4MP@25, 2 x 3MP@30,4 x 1080P@25, 8 x 960P@25, 8 x 720P@30
Hard Disk
SATA	1 SATA interface

Capacity	Up to 6TB for each HDD
External Interface
Network Interface	1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface	Rear panel：2 x USB2.0
Wi-Fi
Frequency	2.4GHz
Transmission Rate	150Mbps
Wireless Standards	IEEE 802.11b/g/n
Wireless Range	280m(open environment)
General
Power Supply	12V DC Power Consumption: ≤ 9 W( without HDD )
Working Environment	-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H)	205mm × 205mm × 46mm (8.1" ×8.1"×1.8")
Weight ( without HDD )	≤0.58Kg(1.28lb)

Model	IPC2122LR3-F40W-E
Sensor	1/2.9", 2.0 megapixel, progressive scan, CMOS
Lens	4.0mm@F2.0
DORI Distance	Lens	Detect(m)	Observe(m)	Recognize(m)	Identify(m)
	4mm	64.3	25.7	12.9	6.4
Angle of view(H)	82.0°
Angle of View (V)	41.4°
Angle of View (O)	100.9°
Shutter	Auto/Manual, 1~1/100000 s
Minimum Illumination	Colour: 0.02 Lux (F2.0 AGC ON) 0 Lux with IR on
Day/Night	IR-cut filter with auto switch (ICR)
Digital noise reduction	2D/3D DNR
S/N	>52dB
IR Range	Up to 30m (98 ft) IR range
Defog	Digital Defog
WDR	DWDR
Video
Video Compression	Ultra 265, H.265, H.264
H.264 code profile	Baseline profile, Main Profile
Frame Rate	Main Stream:2MP (1920×1080): Max. 20 fps; Sub Stream: 720P (1280×720): Max. 20 fps;
HLC	Supported
BLC	Supported
OSD	Up to 4 OSDs
Privacy Mask	Up to 4 areas
ROI	Up to 2 areas
Motion Detection	Up to 4 areas
Network
Protocols	IPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP
Compatible Integration	ONVIF (Profile S, Profile T), API
Wi-Fi
Wireless Standards	IEEE802.11b/g/n
Frequency Range	2.4 GHz ~ 2.4835 GHz

Channel Bandwidth	20 MHz Support
Modulation Mode	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM/HT
Security	64/128-bit WEP, WPA-PSK/WPA2-PSK
Transmit Power	802.11b: 17±1.5dBm @11Mbps 802.11g: 14±1.5dBm @ 54Mbps 802.11n: 12.5±1.5dBm @150Mbps
Receive Sensitivity	802.11b: -90dBm @11Mbps (Typical) 802.11g: -75dBm @54Mbps (Typical) 802.11n: -74dBm @150Mbps (Typical)
Transmission Rate	802.11b: 11Mbps 802.11g: 54Mbps 802.11n: up to 150Mbps
Interface
Network	1 RJ45 10M/100M Base-TX Ethernet
General
Power	DC 12V±25%
Power	Power consumption: Max 4 W
Dimensions (L × W × H)	161.1 × 62.5 × 62.7mm (6.3” × 2.5” × 2.5”)
Weight	0.25 kg (0.55 lb)
Working Environment	-30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing)
Ingress Protection	IP67
Reset Button	Supported
