Uniview - XVR302-08U-IF - UNV 2 Hard Disks 8-Channel 8MP TVI CVI AHD H.265 Hybrid AI Network Video Recorder, Audio over Coax, FR

Uniview - XVR302-08U-IF - Uniview 2 Hard Disks 8-Channel 8MP TVI CVI AHD H.265 Hybrid AI Network Video Recorder, Audio over Coax, FR

Name: Uniview - XVR302-08U-IF - Uniview 2 Hard Disks 8-Channel 8MP TVI CVI AHD H.265 Hybrid AI Network Video Recorder, Audio over Coax, FR
Brand: Uniview
SKU: XVR302-08U-IF
Price: 322.38 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: XVR302-08U-IF

$322.38

~~$802.80~~

Description
Specifications
Downloads
Reviews

UNV 2 Hard Disks 8-Channel 8MP TVI CVI AHD H.265 Hybrid AI Network Video Recorder, Audio over Coax, FR

Features:

Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
Support audio over coaxial cable
8-channel BNC input
Up to 8MP resolution for recording
Support 1-ch HDMI output at up to 4K, 1-ch VGA output at up to 1920*1080
Long transmission distance over coaxial cable
Support 1-ch face recognition with analog camera or third-part IPC
Support 4-ch face recognition with UNV face capture IPC
Up to 16 face libraries, total capacity of 100000 face images

Model	XVR302-08U-IF
Video/Audio Input
Analog Video Input	8-ch, BNC
IP Video Input	8-ch (only IP up to 16ch), each channel up to 4K
Supported Analog Camera Types	Support AHD input: 8MP@15fps 5MP@20fps 4MP@30fps 3MP@30fps 1080P@30fps 720P@60fps Support TVI input: 8MP@15fps 5MP@20ps 4MP@30fps 3MP@20fps 1080P@30fps 720P@60fps Support CVI input:
	8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@60fps Support CVBS input
Audio Input	4-ch, RCA
Two-way Audio	1-ch, RCA
Network
Incoming Bandwidth	80 Mbps
Outgoing Bandwidth	64 Mbps
Remote Users	128
Protocols	TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
CVBS Output	1-ch, BNC
VGA Output	1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
HDMI Output	4K(3840X2160)/30Hz,1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz,1024x768/60Hz
Audio Output	1-ch, RCA
Synchronous Playback	8-ch
Encoding
Recording Frame Rate	Main stream: 8MP@8fps 5MP@12fps 4MP@15fps 3MP@18fps 2MP@25fps 720P@30fps Sub stream: D1@30fps (Max)
Recording Resolution	8MP/5MP/4MP/3MP/1080P/960P/720P/960H/4CIF/CIF
Hard Disk
SATA	2 SATA interfaces
Capacity	up to 6TB for each HDD
External Interface
Network Interface	1-J45 10M/100M/1000M self-adaptive Ethernet Interface
USB Interface	Rear panel：1 x USB3.0, Front panel：1xUSB2.0
Serial Interface	1 x RS485
Alarm In	8
Alarm Out	4
General
Power Supply	12V DC Power Consumption: ≤ 12 W without HDD)
Working Environment	-10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing)
Dimensions(W×D×H)	380mm ×318mm× 53.5mm (14.96" × 12.51"×2.1")
Weight (without HDD)	≤2.0 Kg (4.4lb)

XVR302-08U-IF_a260527c-2790-41f4-bb7a-b96797cb64f2.pdf:
