Hanwha - WRN-816S-8TB - 1U WAVE PoE NVR (Intel based) with 4 Professional licenses, 8TB RAW, supports: 16 channels with 8 PoE/PoE+ ports (PoE Budget 100W), Wisenet WAVE pre-installed, H.264/H.265/MJPEG, 2 fixed internal SATA HDDs (10TB max per HDD),

Hanwha - WRN-816S-8TB - 1U WAVE PoE NVR (Intel based) with 4 Professional licenses, 8TB RAW, supports: 16 channels with 8 PoE/PoE+ ports (PoE Budget 100W), Wisenet WAVE pre-installed, H.264/H.265/MJPEG, 2 fixed internal SATA HDDs (10TB max per HDD),

Name: Hanwha - WRN-816S-8TB - 1U WAVE PoE NVR (Intel based) with 4 Professional licenses, 8TB RAW, supports: 16 channels with 8 PoE/PoE+ ports (PoE Budget 100W), Wisenet WAVE pre-installed, H.264/H.265/MJPEG, 2 fixed internal SATA HDDs (10TB max per HDD),
Brand: Hanwha Vision
SKU: WRN-816S-8TB
Price: 2990.52 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: WRN-816S-8TB

$2,990.52

~~$3,954.00~~

Description
Specifications
Downloads
Reviews

1U WAVE PoE NVR (Intel based) with 4 Professional licenses, 8TB RAW, supports: 16 channels with 8 PoE/PoE+ ports (PoE Budget 100W), Wisenet WAVE pre-installed, H.264/H.265/MJPEG, 2 fixed internal SATA HDDs (10TB max per HDD), Wisestream technology, HDMI/DP output, Dual GbE NICs

Features:

Supported by Wave client, mobile and Cloud Sync
Supports AI metadata
150 Mbps of recording throughput
Supports up to 20TB internal storage
HDMI/DP monitor outputs for configuration and basic monitoring
8 PoE/PoE+ ports, with a total power budget of 100W
Includes USB mouse and rack mount brackets

Display
Decoding	Local Display HDMI (1), DP (1)
Performance
Operating System	Embedded Ubuntu 22.04 LTS
Record
Recording Bandwidth Max. 150Mbps	Max. 150Mbps Up to 10TB
Storage	HDD Slot SATA 2ea (Max. 20TB)

Interface
Front	Indicator Power, Network, HDD
HDMI	1EA
DP	1EA
Audio	Audio output
Ethernet	PoE RJ-45(LAN, 10/100) 8 EA, RJ-45 2ea (WAN, 1Gbps)
USB	Front USB 2.0(2), Rear USB 3.0(2)
Environmental
CPU	Dual core
RAM	DDR4 8GB
OS HDD	eMMC 32GB
Operating Temperature	0°C to +40°C (32℉to 104℉)
Operating Humidity	20% ~ 85% RH
Electrical
Power Input	100 ~ 240 VAC ±10%; 50/60 Hz
Power Consumption	170W
PoE Budget	100W
Mechanical
Color / Material	Black / Metal
Dimension (WxHxD)	370.0 x 50.7 x 320 mm
Weight	2.78Kg

DataSheet_WRN-816S_250303_EN_1_22138819-4279-4fad-938f-135d2f0d396b.pdf:

WRN-Network-Configuration-Manual-10172024_17_b9c1d0ca-f0fe-41ef-a8db-ef77f274b841.pdf:
