24%

Hanwha - WRR-P-E201S-64TB - 1U Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 64TB raw (43TB usable after disk formatting & RAID 5 configuration), 470 Mbps recording B/W, 4 HDD Bay (3.5

Hanwha - WRR-P-E201S-64TB - 1U Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 64TB raw (43TB usable after disk formatting & RAID 5 configuration), 470 Mbps recording B/W, 4 HDD Bay (3.5"), Intel Xeon E23

Name: Hanwha - WRR-P-E201S-64TB - 1U Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 64TB raw (43TB usable after disk formatting & RAID 5 configuration), 470 Mbps recording B/W, 4 HDD Bay (3.5"), Intel Xeon E23
Brand: Hanwha Vision
SKU: WRR-P-E201S-64TB
Price: 15663.78 USD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: WRR-P-E201S-64TB

$15,663.78

~~$20,718.00~~

Description
Specifications
Downloads
Reviews

1U Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 64TB raw (43TB usable after disk formatting & RAID 5 configuration), 470 Mbps recording B/W, 4 HDD Bay (3.5"), Intel Xeon E2356G, 16GB RAM, Dual 480GB SSD OS drives (RAID 1), Windows Server 2022, Support RAID 0/1/5/6 + 512MB NV cache, HDMI output, VGA output, 2 x 1GbE NICs, IPMI, Redundant 450W power supplies, Keyboard and mouse included, Rail kit included

Features:

1U Wisenet WAVE Network Video Recorder with 4 Professional licenses
Wisenet WAVE pre-installed
max 80TB raw (54TB usable after disk formatting & RAID 5 configuration)
470 Mbps recording B/W
4 HDD Bay (3.5")
Intel Xeon E2356G
16GB RAM
Dual 480GB SSD OS drives (RAID 1)
Windows Server 2022
Support RAID 0/1/5/6 + 512MB NV cache
HDMI output
VGA output
2 x 1GbE NICs
IPMI
Redundant 450W power supplies
Keyboard and mouse included
Rail kit included

System
Video Management Software	Wave VMS
Recording Bandwidth	Up to 470 Mbs * Bandwidth performance figures based on performance testing by Hanwha Vision using Wave VMS
Included Licenses	4 x Wave Professional License
OS Drive Bays	2 x 480GB Dual RAID 1 SSD (Internally Mounted)
Data Drive Bays	4 x 3.5" Front Hot Swappable Bays
Data Storage	Up to 80TB raw storage
Network Interface	2 x RJ45 GbE (default), 2 x RJ45 + 2 x 10GbE RJ45 (optional)
Memory	16GB, 2 x 8GB DDR4
Operating System	Windows 10 IoT Enterprise LTSC 2021 / Windows Server 2022 Standard / Ubuntu 22.04 LTS

USB Ports	2 x USB 3.2 (Front), 2 x USB 3.2 (Rear)
Other Ports	Serial
Keyboard & Mouse	Included
Sliding Rail Kit	Included, with Cable Management Arm

Dimensions (WxDxH):

17.3"(440mm) x 19.6"(498mm) x 1.7"(44mm)

Weight: 50 lbs (23 kg)

* Weight is on chassis without HDD's

Electrical

Power Input: 100 - 240 VAC
