EnGenius - N-EnStationAC Kit - Two EnStationAC

Standards
EnStationAC	IEEE 802.11a/n/ac
EnStation5	IEEE 802.11a/n
EnStation2	IEEE 802.11b/g/n
Data Rates
EnStationAC	Up to 867 Mbps on 5 GHz
EnStation5	Up to 300 Mbps on 5 GHz
EnStation2	Up to 300 Mbps on 2.4 GHz
Internal Antennas
EnStationAC / EnStation5	(1) 19 dBi 5 GHz High-Gain Directional
EnStation2	(1) 13 dBi 2.4 GHz High-Gain Directional
Physical Interface
EnStationAC	(1) 10/100/1000 Mbps Port supports 802.3at/Proprietary 48V-54V PoE Input (1) 10/100/1000 Mbps Port supports 802.3af PSE Output
EnStation5 / EnStation2	(1) 10/100 Mbps Port supports Proprietary 24V PoE Input (1) 10/100 Mbps Port supports extension of an Internet signal
LED Indicators
Indicators	1 x Power, 1 x LAN 1, 1 x LAN 2, 1 x WLAN
Reset Button	Yes
Power
Power Source (PoE Adapter) - EnStationAC	802.3at/48V-54V Proprietary Compliant Source, Active Ethernet (Power-over-Ethernet, PoE+)
Power Source (PoE Adapter) - EnStation5 / EnStation2	24V/.6A Proprietary Compliant Source, Active Ethernet (Power-over-Ethernet, PoE)
Power Consumption - EnStationAC	23.4W
Power Consumption - EnStation5	7W
Power Consumption - EnStation2	7.2W
Wireless & Radio Specifications
Operating Frequency - EnStationAC / EnStation5	5 GHz
Operating Frequency - EnStation2	2.4 GHz
Operation Modes	Access Point, Client Bridge, WDS Mode
Transmit Power	Up to 26 dBm, Up to 400 mW Max Power is limited by regulatory power
Radio Interface - EnStationAC	11a/n/ac: 5.180-5.825 GHz
Radio Interface - EnStation5	11a/n: 5.180-5.825 GHz
Radio Interface - EnStation2	11b/g/n: 2.412-2.472 GHz
Radio Chains/Spatial Streams	2x2:2 MIMO
Supported Data Rates (Mbps)
EnStationAC	802.11a: 6, 9, 12, 18, 36, 48, 54 802.11n: 6.5~300 (MCS0 to MCS15) 802.11ac: 6.5~866 (MCS0 to MCS9)
EnStation5	802.11a: 6, 9, 12, 18, 36, 48, 54 802.11n: 6.5~300 (MCS0 to MCS15)
EnStation2	802.11b: 1, 2, 5.5, 11 802.11g: 6, 9, 12, 18, 36, 48, 54 802.11n: 6.5~300 (MCS0 to MCS15)
Supported Radio Technologies
EnStationAC	802.11a/n/ac: Orthogonal Frequency-Division Multiplexing (OFDM)
EnStation5	802.11a/n: Orthogonal Frequency-Division Multiplexing (OFDM)
EnStation2	802.11b: Direct-Sequence Spread-Spectrum (DSSS) 802.11n: Orthogonal Frequency-Division Multiplexing (OFDM)
Channelization
EnStationAC	802.11ac with 20/40/80 MHz Channel Width 802.11n with 20/40 MHz Channel Width 802.11a with 20 MHz Channel Width
EnStation5	802.11n with 5/10/20/40 MHz Channel Width 802.11a with 5/10/20 MHz Channel Width
EnStation2	802.11n with 5/10/20/40 MHz Channel Width 802.11b/g with 5/10/20 MHz Channel Width
Supported Modulation
EnStationAC	802.11a/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, OFDM & 256-QAM
EnStation5	802.11a/n: BPSK, QPSK, 16-QAM, 64-QAM
EnStation2	802.11b: BPSK QPSK, CCK 802.11n: BPSK, QPSK, 16-QAM, 64-QAM
Management
Features	Auto Channel Selection, Multiple SSIDs: 8 SSIDs, BSSID Support, VLAN Tagging - Independent VLAN settings can be enabled/disabled, VLAN Pass-through - Over WDS Bridge Mode, VLAN Per SSID - Isolate each SSID with Individual VLAN, Wireless STA (Client) Connection List, Email Alert, Client Traffic Status
Configuration
Interfaces & Protocols	Web Interface (HTTPS), SSH, SNMP V1/v2c/v3 Support, MIB I/II, Private MIB, CLI Support, Save Configurations as Default
Control Features
Features	RADIUS Accounting - Helps operators to offload 3G to Wi-Fi seamlessly, CLI Commands Support, Distance Control (Ack Timeout), Multicast Supported, RSSI Threshold, Wi-Fi Scheduler
Security
Features	WEP Encryption: 64/128/152 bit, WPA/WPA2 Personal (WPA-EAP using TKIP AES), WPA/WPA2 Enterprise (WPA-EAP using TKIP AES), Hide SSID in Beacons, MAC Address Filtering (Up to 32 MAC addresses per SSID), 802.1x Authenticator
QoS	Compliant with IEEE 802.11e Standard
Environmental & Physical
Temperature Range (Operating)	-4 °F to 140 °F (-20 °C to 60 °C)
Temperature Range (Storage)	-22 °F to 176 °F (-30 °C to 80 °C)
Humidity (Operating, non-condensing)	90% or less
Humidity (Storage, non-condensing)	90% or less
Waterproof	IP55-Rated Enclosure
Dimensions & Weights
EnStation Device (Without Mounting Kit)	Weight: 1.01 lbs. (460 g) Depth: 7.48" (190 mm) Height: 1.50" (38 mm)
Packaging	Weight: 2.29 lbs. (1.04 kg) Width: 9.72" (247 mm) Length: 12.63" (321 mm) Height: 3.46" (88 mm)
Package Contents
Included Items	EnStation Outdoor CPE, Pole/Wall Mounting Kit, Mounting Screw Set, Quick Installation Guide, PoE Adapter (EPA5006GP)
Certifications
Regulatory	FCC, CE
Warranty
Duration	1 Year
