15% $4,182.45
ExacqVision
ExacqVision - 4808-32T-R4ZL-E - 24 TB Z-Series hybrid 4U recorder enterprise linux with 8 IP cameras licenses and 48 analog inputs
Product SKU: 4808-32T-R4ZL-E
Available:
Only 0 item in stock
0 item in stock
In stock
Pre-order
Out of stock
$24,398.55
Rackmount 4U cameras with 8 IP licenses, 48 analog inputs (no looping), RS-485 serial port, 8 alarm inputs, 1 alarm output, 48 audio inputs, dual GB NIC, HDMI, DVI-D, VGA (2 max. simultaneous), RAID 6, Ubuntu Linux 18.04 on SSD, redundant power supplies, keyboard and mouse, exacqVision Enterprise client and server software pre-installed, 3 year warranty and 5 year software updates.
High Performance Network Video Recorders
- Continuously record up to 1,200 Mbps of video for high concentration of HD cameras
- Support many simultaneous video to web/mobile clients with 1800 frames per second video
- Simultaneously connect up to 500 remote clients
- Optional dual 10 Gbps network interfaces for fastest archiving or mass client performance
High Reliability Network Video Recorders
- Continuously record during single power source failure with dual power supplies
- Enterprise-class, continuous-duty hard drives
- Hot spare drive options for automatic replacement of failed drive
- Uninterrupted operation and video preservation in event of one or two drive failures via RAID 5 or RAID 6
- Solid state drive (SSD) for Linux or Windows operating system. Optional RAID 1 protected dual SSDs
- Monitors hardware health in exacqVision client and with email/text notifications
- ESM Failover feature protects against system failures (requires ESM and hardware)
High Capacity Network Video Recorders
- Record up to 128 IP cameras and 64 analog cameras
- Includes 8 IP camera licenses
- Compatible with Thousands of IP camera models
- Store up to 240TB with front accessible storage
- Expandable to over 1.6PB with S-Series networked storage
- Compatible with all exacqVision network recorders and VMS software for maximum scalability
VMS Software:
-
Pre-configured with exacqVision Professional VMS software (standard)
- EasyConnect − automatically finds, addresses and connects IP cameras
- Two-way audio
- Powerful integration with retail security, financial and access control systems
- Conduct investigations on recorded video, audio and data with thumbnail or timeline search
- Bookmark important video for long-term retention
- Video multi-streaming to optimize storage utilization and network traffic
-
View video anywhere (standard)
- Unlimited Windows/Linux/Mac PC clients
- Live and recorded video from any browser
- Live and recorded video from most tablets and smartphones
-
Upgrade to exacqVision Enterprise software (optional)
- VideoPush to remotely control video wall clients
- Case Management to organize critical evidence
- Active Directory / LDAP for IT administration of users
- Easy, single-screen administration of cameras, users, storage and notifications
-
Enterprise System Manager (optional)
- Maximize uptime with health monitoring
Host Certified Software Applications (CSA)
- Ability to host CSAs such as video analytic or point-of-sale interfaces on the servers
- Tested by Exacq for reliable operation
- Save money on hardware and support costs and rack space by loading multiple applications on one server
3-Year Warranty and 5-Year Software Subscription Agreement (SSA)
- Constantly increase VMS software features with included regular software updates
- 5 years of unlimited software updates included
- 3 years of system warranty
- Add optional annual on-site video recorder repair service to diagnose and resolve issues faster within the continental United States
| Specifications | Z-Series Hybrid 2U | Z-Series Hybrid 4U |
|---|---|---|
| Maximum IP Cameras | 128 | 128 |
| Maximum Analog Cameras | 16 or 32 | 16, 32, 48, or 64 |
| Included IP Licenses | 8 | 8 |
| Pre-Loaded VMS Software | Professional Enterprise | Professional Enterprise |
| Include SSA | 5 Years | 5 Years |
| Operating System | Windows 10 Linux Ubuntu 18.04 Windows Server 2019 (Optional) | Windows 10 Linux Ubuntu 18.04 Windows Server 2019 (Optional) |
| RAID | RAID 5 | RAID 6 |
| Maximum Storage | 96 TB | 240 TB |
| Maximum Hard Drives | 8 | 20 |
| Typical Video Storage Rate | 400 Mbps (Windows) 800 Mbps (Linux) | 800 Mbps (Windows) 1200 Mbps (Linux) |
| Local Client Display Rate (1080p) | 700 FPS (Windows) 900 FPS (Linux) | 700 FPS (Windows) 900 FPS (Linux) |
| CPU | Intel Core i7 Intel Xeon (Optional) | Intel Core i7 Intel Xeon (Optional) |
| RAM | 16 GB 32 GB (Optional) | 16 GB 32 GB (Optional) |
| Operating System Drive | 128 GB SSD | 128 GB SSD |
| Operating System Redundancy | RAID 1 (Optional) | RAID 1 (Optional) |
| Monitor Output | DVI-D, HDMI, VGA 2 Simultaneous | DVI-D, HDMI, VGA 2 Simultaneous |
| NIC | 2 x 1 Gbps 4 x 1 Gbps (Optional) 2 x 10 Gbps SPF+ (Optional) | 2 x 1 Gbps 4 x 1 Gbps (Optional) 2 x 10 Gbps SPF+ (Optional) |
| USB | 2 x USB 2.0, 4 x USB 3.0 | 2 x USB 2.0, 4 x USB 3.0 |
| Alarm Inputs | 16 TTL External USB I/O (Optional) | 16 TTL External USB I/O (Optional) |
| Alarm Outputs | 15 TTL & 1 relay External USB I/O (Optional) | 15 TTL & 1 relay External USB I/O (Optional) |
| Audio Inputs | 16 | 16 |
| Audio Outputs | 4 | 4 |
| Analog Outputs | 1 (16-Channel), 2 (32-Channel) | 1 (16-Channel), 2 (32-Channel), 3 (48-Channel), 4 (64-Channel) |
| DVD | External (Optional) | Internal or External (Optional) |
| Accessories | Keyboard, Mouse | Keyboard, Mouse |
| Dimensions (H x W x D) | 3.5 x 17 x 24 in 8.9 x 43.18 x 60.96 cm | 7.0 x 16.875 x 27 in 17.8 x 42.9 x 68.6 cm |
| Weight | 34 - 50 lbs 15.4 - 22.7 kg | 49 - 90 lbs 22.3 - 40.9 kg |
| Regulatory |  | |
| Input Voltage | 120/240 VAC auto-sensing | 120/240 VAC auto-sensing |
| Power Supplies | Redundant | Redundant |
| Power & Heat | 240 Watts/790 BTU/h (Max) 170 Watts/570 BTU/h (Typical) | 390 Watts/1320 BTU/h (Max) 210 Watts/700 BTU/h (Typical) |
| Operating Temperature | 40° - 95°F 4.5° - 35°C | 40° - 95°F 4.5° - 35°C |
| Warranty | 3 Years | 3 Years |
